Deployment of a Machine Learning model into Amazon EC2 (Part 1- Warm-up of EC2)
- In the previous article, we saw how to deploy a machine learning model into the local box.
- Now, we will be deploying the model on Amazon EC2.
- Before doing that, let’s first set up the environment for our trained machine learning model.
- This can be done using Amazon EC2 through the following steps:
Sign in to AWS Management Console:
- In order to deploy a model into Amazon EC2, at first, we will have to be familiar with the Amazon Web Services Dashboard.
- So, sign up and make an AWS account by visiting https://aws.amazon.com/ and clicking on the signup button.
- For a reference on how to sign up for amazon web services, you can refer to this video.
- Now after signing in into the AWS accounts and after the validation checks, you will land on the AWS Management Console.
- After successful registration, search for EC2 in the search bar and click on Launch Instances.
- After you have successfully launched the instances, you’ll have to select the machine type.
- Here, we will be using the free tier which gives us a Linux box with 2GB of RAM hence, we will select the Amazon Linux 2 AMI.
- After that, you can continue the setup as per the default settings (using a t2.micro instance) and click Review and Launch.
- Upon selecting the Launch button you’ll have to select a key pair.
- You can create your own new key pair.
- After the successful creation of the key pairs, you can simply download them into your local system. It will be saved as a pem file.
- Now you’ll have to navigate back to the EC2 instances page the same way by searching EC2 on the search bar.
- Then click on the instance that you have just launched.
- After that, click on the Security tab at the bottom of the console and over there you can see a link in the form — sg-0aa552bfee276b14d.
- On the next page scroll to the bottom and go to Edit Inbound Rules.
- In the Inbound rules, add an All traffic rule with
0.0.0.0/0CIDR block and then save.
Setup Putty for Deployment:
- As for the next course of action, one is supposed to download and install PuTTy as per the default presets.
- Next, one should open PuTTYgen from Windows.
- After that, the pem file needs to get loaded that was downloaded initially.
- Keep in mind you keep all the files in the same directory otherwise it will challenging to connect to the right EC2 instance in AWS.
- After the pem file is successfully loaded, one should save the file as a .ppk (for example filename.ppk) format in the same directory of the pem file.
- After the setup of Putty, you need to download WinSCP from here.
- One should keep in mind that at the time of the installation it should be a Typical Installation.
- The user interface style should be selected as Commander.
- Now as we open the WinSCP application we can see a hostname needs to be passed.
- In order to find the hostname go to the EC2 instance, select it and click on connect.
- After that click on SSH Client.
- Here, you can find your hostname as ec2–54–198–143–216.compute-1.amazonaws.com.
Please note that you’ll be getting a different hostname from your AWS Management Console.
- You need to copy the hostname and paste it into the hostname section of WinSCP.
- After that enter the username and click on Advanced.
- After that click on authentication and select the three dots in the private key file section.
- Over there, you’ll have to select the ppk file that was created and click open.
- After that, click on Login and a popup window should open in front of you. Click on Yes.
- In case you face any error please do have a look at the username.
Usually, the usernames are ec2-user, ubuntu, centos, root, or admin.
- You can read about the common error and how to resolve it here.
- After the connection is established successfully, you’ll have to drag and drop the necessary files.
- For this project, we have selected app.py, templates, the pickle file, and requirements.txt.
Installation of the required libraries into the server:
- Now one issue is that, in the server, most of the libraries are not yet installed, and hence, we will have to manually install all the libraries.
- In order to do so, open Putty.
- Paste the hostname in the Host Name (or IP address) section.
- Give a session name, here we have given MLDemoTest as the session name.
- Next, click on SSH.
- Next to the SSH button, you’ll find a (+) sign click that and then click on Auth.
- Click Browse and feed the ppk file.
- Now go to the session and click on save.
- After that click on the session name and open it.
- Now you can see that you’re able to access the terminal of that particular Linux server.
- You’ll have to pass on the username and you can see yourself logged in to the Linux server.
- Now use the following command in order to install python 3 into the Linux box.
sudo yum install python3-pip
- So far in this article, we covered a high-level overview of how to set up our server into Amazon EC2.
- We understood the setup of a Linux box.
- In the next article, we will see how to deploy the trained machine learning model into Amazon EC2.
